PNEUMATIC RUBBER FENDER

Pneumatic Rubber Fenders have been in use for around 50 years. It is the leading anti-collision device for marine application in the world. This compressed air filled rubber fender is used as a protective medium for ship-to-ship contact (STS), ship to quay (STQ) and ship-to-berthing (STB).
FEATURES• Easy and fast to deploy • Very low reaction and hull pressure • Performance adjustable by varying initial pressure • Suitable for areas with large or small tides • Maintains large clearances between hull and structure • Optional chain-tyre nets for heavy duty applications

product-687-253

image003_副本

SPECIFICATION

Initial Pressure	50kPA	50kPA	50kPA	80kPA	80kPA	80kPA
Model D*L (mm)	Energy (kNm)	Reaction (kN)	"Pressure (kN/m2)"	Energy (kNm)	Reaction (kN)	"Pressure (kN/m2)"
FL 500x1000	6	64	132	8	85	174
FL 600x1000	8	74	126	11	98	166
FL 700x1500	17	137	135	24	180	177
FL1000x1500	32	182	122	45	239	160
FL 1000x2000	45	257	132	63	338	174
FL 1200x2000	63	297	126	88	390	166
FL 1350x2500	102	427	130	142	561	170
FL 1500x3000	153	579	132	214	761	174
FL 1700x3000	191	639	128	267	840	168
FL 2000x3500	308	875	128	430	1150	168
FL 2500x4000	663	1381	137	925	1815	180
FL 2500x5500	943	2019	148	1317	2653	195
FL 3300x4500	1175	1884	130	1640	2476	171
FL 3300x6500	1814	3015	146	2532	3961	191
FL 3300x10600	3067	5257	158	4281	6907	208
FL 4500x9000	4752	5747	146	6633	7551	192
FL 4500x12000	6473	7984	154	9037	10490	202

DETAILS OF PNEUMATIC FENDER

1. Pneumatic rubber fender
2. Shackle
3. Tyre-net
4. Chain system
5. Anchors
6. Rubber hose

P.S. The sizes listed above are partial and only for reference, other sizes besides the above can be customized. Contact us for specific model capacities and safety factors.

APPLICATION

• Tankers, Gas Carriers and Bulk Cargo Ships

• Fast ferries and aluminum hulled vessels

• Temporary or permanent installations

• Rapid response and emergency fendering

• As stand-off fenders to realign ships with shore facilities

FAQ

Q: What is a Pneumatic Rubber Fender used for?
Pneumatic Rubber Fenders are used for ship-to-ship and ship-to-dock berthing protection.

Q: What sizes are available for Pneumatic Rubber Fenders?
Standard diameters range from 500 mm to 4500 mm, with lengths up to 12000 mm.

Q: What internal pressure do Pneumatic Fenders use?
Common initial internal pressures are 50 kPa and 80 kPa.

Q: What are the advantages of Pneumatic Rubber Fenders?
They provide high energy absorption, low reaction force, and excellent floating performance.

Q: What is the lifespan of Pneumatic Rubber Fenders?
With proper maintenance, service life is typically 10–15 years.
