High Quality Marine Pneumatic Rubber Fender

High Quality Marine Pneumatic Rubber Fender

**Advantages:**

1. High energy absorption capacity.

2. Easy installation and maintenance due to a simple design.

3. Widely applicable to vessels and wharfs of any size.

4. Effectively absorbs the majority of impact energy caused by pitching and rolling when a ship is alongside.

5. Low unit-area pressure acting on the vessel.

6. Excellent resistance to impact fatigue.

**Features:**

1. Initial pressure options: 0.05 MPa and 0.08 MPa are available.

2. Standards: Compliant with the latest ISO 17357-2002 directives.

3. Accessories: A variety of chains, anchors, and shackles can be provided.

4. Customizable sizes to meet specific requirements.

The rubber inflatable fenders are constructed of three key components, each playing a critical role in the structural integrity and lifespan of the fender.
1. **Outer Rubber Layer**:

A protective rubber layer that encapsulates the exterior of the fender, safeguarding the synthetic cord layers and inner liner rubber from abrasion and other external forces.
2. **Inner Rubber Layer**:

A sealing rubber membrane that ensures the containment of pressurized air within the fender.
3. **Synthetic-Tyre-Cord Reinforcement Layer**:

A reinforcing layer made of synthetic tyre-cord fabric, which maintains the internal air pressure and structural stability of the fender.

The following factors should be taken into consideration when selecting inflatable marine fenders:

(1) Maximum energy absorption ;

(2) Reaction force;

(3) Berthing distance requirements between two vessels or between a vessel and a dock, including both the maximum and minimum distances;

(4) Vessel size;

(5) Environmental factors such as wind waves and temperature variations in the actual operating conditions.

The selection of a pneumatic fender system first requires determining the collision energy of the vessel during berthing and post-berthing operations. The specifications of the pneumatic fender should then be chosen based on berthing distance requirements (maximum and minimum distances), followed by verifying whether the maximum reaction force of the pneumatic fender falls within the allowable range of the hull's design parameters.

If it is necessary to enhance the energy absorption capacity of the pneumatic fender, increasing its diameter is an ideal option. The number and spacing of pneumatic fenders are determined according to the vessel's size and specific operational requirements.
