Marine Vessel Launching Airbags

Qingdao Florescence Marine Supply is one of the earliest manufacturers of marine airbag, our products can totally meet the ISO 14409 standard. The working pressure can up to 600kipa and is able to carry 200000 DWT ship launching, lead and innovate the relevant safety technology of ship airbag in ship discharge and launching. Compared with the traditional launching method, the Marine airbag is of great environmental protection, because the Marine airbag can assist the ship launching at any seaside, so there is no need to worry about the construction of launching facilities. Our Marine airbags enjoy a high reputation all over the world, not only in Asia but also in Africa, the Middle East, Oceania, South America and North America.

Structure

Airbag cylindrical body, conical head and air inflate end.

Material

An airbag is to be constructed of an outer rubber layer, one or more synthetic-tyre-cord layers, and an inner rubber layer. The arrangement of synthetic-tyre-cord reinforcement layers is shown in the picture below, all materials shall be vulcanized firmly.

Airbags safety & storage

Safety precaution

1. Over pressure Control:

Strictly control the operating pressure, over pressure is forbidden.

2. The Landing Slipway Requirements:

The landing ground should be ground or cement concrete, according the tonnage of different ships.

3. Avoid Sharp Objects:

Make sure no sharp objects and make sure the smooth and clean ground during using them in case of break of airbag.

Storage

1. When the airbags are not to be used for a long time, they should be drained, cleaned, dried, filled with talc power, and the exterior surfaces should be coated with talc powe

2. The airbags should be maintained in a dry ventilated room and be protected from light.

3. The airbags should be kept away from any heat source.

1. For ship upgrading, conversion or new/repair launching;

2. Marine airbag for salvaging sunken ship or heavy immersed steel structure;

3. For hoisting and transporting heavy goods up to 10,000 tonnes structure on land;

4. For heavy lifting;

5. Inflatable mandrel for construction;

6. For tunnel culverts to stop leaks.

Feature:

1. Different airbag size stock available, quick delivery;

2. More safety: Nylon-6 Dipped Cord fabric, 3chords,single strength>313N,1.5times than commons;

3. Long time service life can be reused many times;

4. Wear resistance and anti aging;

5. High strength: The skeleton material is more than 1.5 times stronger than normal airbag;

6. Do no harm to the environment. Time & money saving;

7. Need no more than air compressors, winches and ropes;

8. Good air tightness, far beyond international standards.
